January 11th, 2009
Ever wondered how to connect your linux box via bluetooth, for instance to allow file transfer with your phone?
I found some cool and working hints on the Net, reporting here below what worked for me.
- Connect your USB dongle
- Install what you need:
apt-get install obexftp bluetooth
- Then you need to set the system to use a predefined PIN, since you have no console and very probably you would like to digit only from phone side to connect with this box.
To do this, you need to edit file /etc/bluetooth/hcid.conf to change the following defaults:
# Security Manager mode
# none – Security manager disabled
# auto – Use local PIN for incoming connections
# user – Always ask user for a PIN
#
security auto; <== this is set by default to user
and
# Default PIN code for incoming connections
passkey "58336342"; <== this is set by default to 1234, not enough secure IMHO…
Now, back to cellular connections:
- Scan for cellular address:
hcitool scan
this will return the address of your device, like:
magicbox:~# hcitool scan
Scanning …
00:17:E4:82:F4:64 RoarinPenguin
- Now we need to search the channel for file tranfers
magicbox:~# sdptool browse 00:17:E4:82:F4:64
This will return all details about services provided by the phone:
magicbox:~# sdptool browse 00:17:E4:82:F4:64
Browsing 00:17:E4:82:F4:64 …
Service Name: AVRCP Target
Service Description: Audio Video Remote Control
Service Provider: Symbian Software Ltd.
Service RecHandle: 0×10000
Service Class ID List:
"AV Remote Target" (0×110c)
Protocol Descriptor List:
"L2CAP" (0×0100)
PSM: 23
"AVCTP" (0×0017)
uint16: 0×100
Profile Descriptor List:
"AV Remote" (0×110e)
Version: 0×0100
Service RecHandle: 0×10001
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 1
Service Name: Dial-Up Networking
Service RecHandle: 0×10002
Service Class ID List:
"Dialup Networking" (0×1103)
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 2
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"Dialup Networking" (0×1103)
Version: 0×0100
Service Name: OBEX Object Push
Service RecHandle: 0×10003
Service Class ID List:
"OBEX Object Push" (0×1105)
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 9
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"OBEX Object Push" (0×1105)
Version: 0×0100
Service Name: Hands-Free Audio Gateway
Service RecHandle: 0×10004
Service Class ID List:
"Handfree Audio Gateway" (0×111f)
"Generic Audio" (0×1203)
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 28
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"Handfree Audio Gateway" (0×111f)
Version: 0×0101
Service Name: Headset Audio Gateway
Service RecHandle: 0×10005
Service Class ID List:
"Headset Audio Gateway" (0×1112)
"Generic Audio" (0×1203)
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 29
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"Headset" (0×1108)
Version: 0×0100
Service Name: Imaging
Service RecHandle: 0×10006
Service Class ID List:
"Imaging Responder" (0×111b)
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 15
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"Imaging" (0×111a)
Version: 0×0100
Service Name: SyncMLClient
Service RecHandle: 0×10007
Service Class ID List:
UUID 128: 00000002-0000-1000-8000-0002ee000002
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 10
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"" (0×00000002-0000-1000-8000-0002ee000002)
Version: 0×0100
Service Name: OBEX File Transfer
Service RecHandle: 0×10008
Service Class ID List:
"OBEX File Transfer" (0×1106)
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 11
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"OBEX File Transfer" (0×1106)
Version: 0×0100
Service Name: Nokia OBEX PC Suite Services
Service RecHandle: 0×10009
Service Class ID List:
UUID 128: 00005005-0000-1000-8000-0002ee000001
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 12
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"" (0×00005005-0000-1000-8000-0002ee000001)
Version: 0×0100
Service Name: SyncML DM Client
Service RecHandle: 0×1000a
Service Class ID List:
UUID 128: 00000004-0000-1000-8000-0002ee000002
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 13
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"" (0×00000004-0000-1000-8000-0002ee000002)
Version: 0×0100
Service Name: Nokia SyncML Server
Service RecHandle: 0×1000b
Service Class ID List:
UUID 128: 00005601-0000-1000-8000-0002ee000001
Protocol Descriptor List:
"L2CAP" (0×0100)
"RFCOMM" (0×0003)
Channel: 14
"OBEX" (0×0008)
Language Base Attr List:
code_ISO639: 0×454e
encoding: 0×6a
base_offset: 0×100
Profile Descriptor List:
"" (0×00005601-0000-1000-8000-0002ee000001)
Version: 0×0100
- The interesting channel for us is Obex File Transfer, thus 11. Let’s browse what telefone has to offer:
obexftp -b 00:17:E4:82:F4:64 -c / -l
This command will access the cellular of the given address the "/" (root) directory and will list its contents
Now, once could ask how to send files to the mentioned box. Well, so far I have discovered how to “pull” them from the box from the phone using obexftp command as follows:
obexftp -b 00:17:E4:82:F4:64 -c /<path_on_the_phone> -g picture1.jpg
There should be another way to put the box in listening mode through rfcomm command, but that’s food for another article
since I have first to read and “digest” articles like this one…
